VCH Series Chain Hoist, 20' Lift, 2200 lbs. (1 tons) Capacity, Heat-Treated Alloy Steel Chain

• Professional grade triple spur gear is lightweight and portable
• Dual pawl Weston-style brake provides safe and reliable operation
• Made with premium grade non-asbestos brake discs for long service life
• Made with grade 80 heat-treated alloy steel load chain
• Load tested to 150% of rated capacity and includes certificate
• Top and bottom safety hooks are engineered to bend lowly in case of accidental overload
• Load Chain Grade

Specifications:
Capacity: 2200 lbs. (1 tons)
Lift: 20'
Chain Material: Heat-Treated Alloy Steel
Standard(s) Met: ISO 9001-2000, ASME B30.16
Head Room: 12-1/16"
Load Chain Diameter: 6 mm
Load Chain Grade: 80
Number Of Falls: 1
Number Of Safety Hooks: 2
Min. Distance Between Hooks: 12-1/16"
Force Required To Lift: 68 lbs.
