Stay-Silv® 5 Brazing Alloys

• Medium-range alloy; useful primarily where fit-up can not be tightly controlled
• Somewhat more ductile than Harris 0
• Typical application: Used to bridge gaps where close fit-up can't be maintained
• Phos/copper and silver/phos/copper alloys are used to braze copper to copper and copper to brass
• The phosphorus content in these alloys makes them self-fluxing on copper
• When brazing brass or copper to brass, use Stay-Silv® white brazing flux
• Specifications

Specifications:
Type: Medium-Silver PhosCopper Brazing Alloy
Description: 0.050 x 1/8 x 28 Stick Tube
Wire Diameter: 1/8"
Material Type: Lead-Free
Composition: 89% Copper 6% Phosphorus 5% Silver
Chemical Composition: 89% Cu, 6% P, 5% Ag
Specifications: AWS A5.8 BCuP-3
Solidus: 1190ºF, 643ºC
Liquidus: 1500ºF, 816ºC
