Pressure Gauge, 4-1/2" , 0 - 5000 psi, Bottom Mount, Liquid Filled Analogue

• Black, impact resistant phenolic case
• 316 stainless steel bourdon tube and socket
• Shatterproof glass lens
• Stamped aluminum 4-1/2" (115 mm) diameter dial
• Micrometer adjustable pointer
• Integral back flange with safety blowout backplate
• Transient Over-Pressure Limit

Specifications:
Dial Diameter: 4-1/2"
Pressure Range: 0 - 5000 psi
Connection: Bottom Mount
Dial Type: Liquid Filled Analogue
Temperature Rating: -50° - 170° F
Connection Thread: 1/4" NPT
Transient Over-Pressure Limit: 30%
Accuracy: 1/2% of Full Scale
Dial Temperature Rating: -50 to 170°F
