Eye Bolt, 1-3/16" Dia., 2" L, Zinc Plated, 650 lbs. (0.325 tons) Capacity

• Never apply loads greater than rated capacity
• Safety Warning: The rated capacity is reduced to 25% when the load is applied at a 45 degree angle to the eyebolt centerline
• Safety Warning: Load should never be applied at more than a 45 degree angle from the bolt centerline
• I.D. Eye

Specifications:
Working Load Limit: 650 lbs. (0.325 tons)
Finish: Zinc Plated
Eye Diameter: 1-3/16"
Shank Length: 2"
Body Style: With Shoulder
Shank Threading: Partially Threaded
I.D. Eye: 3/4"
O.D. Eye: 1-3/16"
Thread Size, UNC-2A: 1/4" - 20"
Overall Dimensions: 3-13/32" L x 1-1/4" W x 1/2" H
Weight: 0.07 lbs.
