• Powerful 1 HP motor
• Quick belt release lever for easy replacement
• Heavy-duty cast-iron construction
• Two 2 1/2" dust chutes with 2 1/2" to 4" adaptor for dust collector hook-up
• Belt plate is covered by a graphite pad which reduces friction and increases belt life
• Adjustable belt unit operates vertically, horizontally, or at any angle in between
• Belt Speed
• 2-Position belt and disc cast-aluminum table tilts from 0° - 45°

Specifications:
Overall Width: 19"
Overall Length: 30"
Overall Height: 56"
Belt Dimensions: 6" W x 48" L
Disk Diameter: 9"
Belt Lift: 0° - 90°
Belt Speed: 1250 SFPM
Disc Speed: 1740 SFPM
Motor: 11.9 A @ 110 V/5.5 A. @ 220 V
Voltage: 110/220 V, 1 phase, 60 Hz
Pre-wired: 110 V
Weight: 135 lbs.
