2000 Series Magnehelic® Vertical Scale Differential Pressure Gauge, 4-3/4" , 0 - 0.125 kPa, Panel Mount, Liquid Filled Analogue

• Calibrated for vertical scale position
• Indicates positive, negative, or differential pressure
• Bezel provides flange for flush mounting in panel
• Clear plastic face is highly resistant to breakage and provides undistorted viewing of pointer and scale
• Red tipped pointer of heat treated aluminum tubing is easy to see
• Pointer stops of molded rubber prevent pointer over-travel without damage
• Jeweled bearings are shock-resistant mounted to provide virtually friction-free motion for helix, and are motion damped with high viscosity silicone fluid

Specifications:
Dial Diameter: 4-3/4"
Pressure Range: 0 - 0.125 kPa
Connection: Panel Mount
Dial Type: Liquid Filled Analogue
Housing Material: Die-Cast Aluminum
Accuracy: ±3%
