Heavy-Duty Manual Trolley - SBT Series, 22000 lbs. (10 tons)

• Specially hardened steel wheels meet ANSI B30.11 specifications (Certificate included)
• Load is moved by pulling on hoist load chain in direction of travel
• Double sealed ball bearings for long life
• Specially designed integrated drop stops/bumpers take the load in the event of wheel failure and prevent wheels from contacting other trolleys on the track
• Adjustable to fit various sizes of flanges and beams
• Comes equipped for use on up to 8" beam widths

Specifications:
Capacity: 22000 lbs. (10 tons)
I-Beam Flange Width: 4-15/16" - 8-1/32"
Curve Radius Size: 67"
Duty Level: Heavy Duty
