Manomètre série B5000, 2-1/2", 0 à 100 psi/0 à 690 kPa, montage inférieur, numérique

• This digital pressure gauge with integral bar graph features 1% accuracy, backlighting for easy reading, and up to 7 selectable engineering units, allowing one gauge to be used in a variety of pressure applications
• Displays real-time pressure with short response times and excellent long-term stability
• The all stainless steel wetted parts make this gauge suitable for a wide variety of industrial liquids and gaseous mediums
• Compatible with air, liquids, and gases
• 4-digit LCD display with backlight provides clear readings
• Push-button zero
• Accuracy

Specifications:
Dial Diameter: 2-1/2"
Pressure Range: 0 - 100 psi/0-690 kPa
Connection: Bottom Mount
Dial Type: Digital
Additional Measuring Ranges: 0 - 7.03 kgf/cm², 0 - 203.6 inHg, 0 - 0.689 Mpa
Resolutions: 0.1 psi, 0.01 kgf/cm², 0.1 inHg, 1 kPa, 0.001 Mpa
Accuracy: 1% F.S.
Long-Term Stability: 0.5% F.S./Year
Sampling Rate: 3x/Sec.
Overload Capacity: 150%
Process Connection: 1/4" Male NPT
Display: 4 Digit Backlit LCD
IP Rating: IP64
