Heavy-Duty Caster, Swivel, 5" (127 mm), Hard Plastic/Nylon, 700 lbs. (317 kg.)

• 9/16" diameter rivet
• 3/8" drilled axle and lock nut
• Corrosion resistant bright zinc finish
• Available with brake
• 1/4" diameter upper raceway
• 1/4" diameter lower raceway (equal diameter raceway) ; Excellent for:
• Bolt Hole Spacing
• Food service equipment

Specifications:
Wheel Diameter: 5" (127 mm)
Capacity: 700 lbs. (317 kg.)
Wheel Material: Hard Plastic/Nylon
Caster Type: Swivel
Frame Material: Steel
Tread Width: 1-1/2" (38 mm)
Bolt Hole Spacing: 2-5/8" - 3" (67 mm x 76 mm) - 3" - 3-5/8" (76 mm - 92 mm)
Bolt Hole Size: 3/8" (9.52 mm)
Plate Size: 4" x 4-1/2" (102 mm x 114 mm)
Bearing Type: Roller
Swivel Radius: 3.3125"
Overall Height: 6.125"
