• Sturdy cast iron frame
• Dual edge, reversible shear blade
• One female "V" shaped die
• Slip rolls are precision turned, ground and polished with wire grooves
• Includes: Adjustable length stop, height stop block and extension bars with 90° angles
• BRAKE Max. Thickness (Mild Steel)

Specifications:
Shear Max. Thickness: 20 Gauge
Shear Max. Length: 40"
Shear Material Stop Range: 3-3/4" - 30"
Brake Max. Thickness: 20 Gauge
Brake Shut Height: 4-1/2"
Brake Material Stop Range: 1/2"- 28"
BRAKE Max. Thickness (Mild Steel): 20 Gauge
BRAKE Male Die Sizes: 15", 10", 7", 4", 2", 1-1/2", 1"
SLIP ROLL Number Of Rolls: 3
SLIP ROLL Max. Thickness (Mild Steel): 20 Gauge
SLIP ROLL Max. Length: 40"
SLIP ROLL Roller Diameter: 2"
SLIP ROLL Min. Radius: 3/4"
Overall Dimensions: 50" L x 30" W x 26" H
Weight: 450 lbs.
